ISONAS IP Reader-Controller, Prox. (125kHz), Wall-mount, Keypad

ISONAS IP Reader-Controller, Prox. (125kHz), Wall-mount, Keypad
ISONAS IP Reader-Controller, Prox. (125kHz), Wall-mount, Keypad
ISONAS IP Reader-Controller, Prox. (125kHz), Wall-mount, Keypad
ISONAS IP Reader-Controller, Prox. (125kHz), Wall-mount, Keypad
- Pure IP Reader-Controller
- Proximity - Wall mount keypad (5.1”x 3.25” x 0.17”)
- Low Frequency, High Frequency and Bluetooth Low Energy
- Local Decision making with host programming
- Made in the USA
- Extension cable: 7.5in
- Adapter: 19mm diameter
- GSA-approved
Price$879.20
MSRP$1,099.00
CodeRC-04-PRX-WK
Weight 2
Save to Wishlist

Power Options - Power Over Ethernet (PoE), (IEEE 802.3af, Class 0)
- DC Power: 12VDC In (9 to 16V)
- PLEASE NOTE: 24V DC is not approved for this device
Network Communications - 10Mb, Half or Full Duplex
- Ethernet, TCP/IP, standard RJ45 Cable
- Network host or client modes supported
- DHCP Addressing Supported
- Field flashable microcode
Software Compatibility - Pure Access Cloud
- Pure Access Manager (On-Premise)
- Legacy ISONAS Software products NOT supported
- DBCrystal and Crystal Matrix, EasyWeb and EasyWeb 2015
Environmental - UL-294 Compliant
- FCC Certified
- Operating Temperatures -40ºF to 135º F (-40ºC to 57ºC)
- Conformal coated for weather resistance
- Exposure Ratings: IP56
Outputs - 8 wire pigtail
- 600mA provided to power the lock
- Conditioned Lock Power
- Fail Safe and Fail Secure Supported
- Two exterior door kit outputs
Inputs -Two configurable inputs:
   - Door Sense
   - General Purpose Request to Exit (REX) or Auxiliary (AUX)
Visual Indicator - LED signal for reader status
- Backlit Keypad
Security Features - Tamper Detection via an accelerometer
Read Range - 3” typical on RFID cards
- Proximity read speed: <250msec
Credential Types - 125 kHz (FSK modulation)
- 13.56MHz
- Bluetooth® Low Energy Supported (4.1 and later)
- Mifare® Classic, Ultralight, and Mifare Plus
- MiFare DesFire EV2 (CSN) ISONAS Only
- iClass (CSN)
- ISO14443A & B
Reader-Controller Intelligence - 64,000 Credentials
- 5,000 Events
- 32 Time Schedules
